TC320
Business Analog Portable Radio
radio
Unique for its compact and professional design, as well as its superb sound quality. Its strong casing prevents
Key Features
Wide Communication Range
2W output power has a range of up to 6 miles.
Durable Casing
Compact durable design that can with stand a 1.5 meter drop
Long Battery Life
1700mAh high capacity Li-Ion battery lasts approximately 12hrs.
User Friendly Design
With its ergonomic design, this slim and compact radio can
Double Injection Molding
The combination of double injection molding and grip
Mini-USB Interface
Chargeable and Programmable through the Mini-USB port, plug
Technical Specifications
| Frequency Range | UHF1: 400 - 470MHz ; UHF2: 450 - 470MHz |
| Channel Capacity | 16 |
| Channel Spacing | 25 / 12.5KHz |
| PLL Channel Stepping | 5 kHz, 6.25 kHz |
| Operating Voltage | 3.7V (rated) |
| RF Power Output | 2W |
| Battery | 1700mAh (Li-Ion) |
| Battery Life (5-5-90 Duty Cycle) | Approx. 10hrs |
| Frequency Stability | 0.5ppm |
| Operating Temperature | -40°F ~ 131°F |
| Antenna Impedance | 50 Ω |
| Dimensions (H x W x D) | 3.94 x 1.89 x 1.06 Inches |
| Weight | 4.76oz |
| FCC ID | See website for full list |
| Canada Industry ID | See website for full list |
