HP56X UL913
Intrinsically Safe DMR Portable Two-way Radio
In a high-risk production environment, safe and efficient instant communication is crucial to ensuring the safety of employees and improving production efficiency. From inside to outside, the HP56X intrinsically safe DMR portable two-way radio can confront any harsh conditions and offer reliable one-to-one or one-to-many communications, without compromising ease of use. Meanwhile, it delivers louder and clearer audio, extended coverage, and longer battery life. So the HP56X empowers your people to work safely and efficiently even in the most demanding environments.
Key Features
UL913 Intrinsically Safe
Certified by SGS and compliant with UL913 and TIA4950 standards, the HP56X is designed for use in hazardous environments with combustible dust, flammable liquids, and explosive gases, ensuring reliable and efficient communications.
Multiple Safety Mechanisms
Equipped with intelligent battery detection to prevent the use of non-explosion-proof batteries, along with Lone Worker and Emergency Alarm features that send location information via GPS and GLONASS to the command center during emergencies.
Superior Audio Quality
Utilizes AI-based noise cancellation technology to suppress feedback howling and filter out unwanted ambient noises, delivering crystal-clear audio in any environment.
High RX Sensitivity
With a sensitivity of 0.18μV (‒122dBm), the HP56X provides exceptional communication coverage, ensuring reliable communications even at the far edge of coverage with weak signals.
Longer-lasting Battery
Features a standard 2,400 mAh Li-ion battery and Hytera's power-saving technology, allowing the radio to operate up to 23 hours in digital mode and high power mode on a 5-5-90 duty cycle.
Rugged Design
Built with a polycarbonate housing that is abrasion and heat resistant, non-slip design, IP67-rated, and meets MIL-STD-810H standards for protection against dust, water, vibrations, 1.5-meter drops, and extreme temperatures.
USB Type-C Port
The USB Type-C port allows for easy programming, upgrading, and charging in non-explosion-proof areas, enhancing the convenience of radio management and usage.
Technical Specifications
| Frequency Range | UHF: 400–470MHz; VHF: 136–174MHz |
| Channel Capacity | 256 |
| Zone Capacity | 16 |
| Operating Voltage | 7.4V (rated) |
| Battery | 2400mAh (typical) |
| Battery Life (5/5/90 Duty Cycle, High TX Power) | Digital: 23h (GPS off), 21h (GPS on) |
| Dimensions (H×W×D) | 119 x 55 x 33.5 mm |
| Weight | 321g |
| Display | 1.45 inch LCD, 240x320 pixels, colorful |
| Anti-explosion Levels | Class I, Division 1, Group C-D, T4; Class II, Class III, Division 1, Group E-G, T135°C; Class I, Division 2, Groups A-D, T4; Ta: -20°C to 60°C |
| Operating Temperature | -20℃ to +60℃ |
| Storage Temperature | -40℃ to +85℃ |
